Fire Alarm Repeater Panel Specification

Repeater network is non redundant and wired in 1 5 mm2 two core screened fire resistant cable.

Fire alarm repeater panel specification.

Repeater panel user manual to be retained by the end user. Communication between the xfp main panel and repeater requires an afp711 network driver card fitted as standard in all xfp510 32s available as an optional extra on main xfp 32 zone panels. The addressable touch screen repeater panel is designed to work as either an active repeater providing a full indication of events and controls or as a passive. What exactly is a repeater panel.

Network length must not exceed 500 metres. Re rpseries is a conventional fire alarm repeater panel. Repeater panels are properly described as repeat control and indication equipment and fall into three main types. This type of repeater will have full indication of events at the main control panel and will also offer fire system controls such as silence reset etc from the repeater.

It repeats function like fire fault supervisory etc that occur on the main panel. Fire detection system repeater panels provide a suitable solution to public spaces such as hotels lobbies or restaurants where the main panel needs to be installed in a restrictive or busy area where it may be damaged and fail. Biwire conventional repeater panel reference efbwcv repeater description repeater panel power specification input voltage range 18 75 30 7v maximum current drawn from battery 2 7a communications ports repeater port use of this port is outside the scope of en54 type rs485 nodes up to 3 repeaters and a fire panel environmental. Re rp series are a range of repeater panels compatible with fire alarm panel.
